Our 6TB Hard Drive Face-Off Revisited

By | April 30th, 2015

6TB Hard Drive Comparison
A few months back we published our initial evaluation of 6TB drives, comparing Seagate (model ST6000DX000) and Western Digital (WD60EFRX). Both drives performed well in our evaluation of 45 drives each, but we wanted to see if the results held up as we scaled the quantity of drives. We now have 450 Seagate and 495 WD drives deployed and as you’ll see, things are a bit different this time around.

Reviewing Our Initial 6TB Hard Drive Comparison

For our initial comparison of the Western Digital and Seagate 6TB drives we installed the drives from each vendor in their own v3.0 Storage Pod. Each pod was identically configured, except for the drives being different. During the evaluation period we measured the amount of data each Storage Pod loaded each day. Our results were somewhat unexpected as the Western Digital drives loaded data faster even though they were spinning slower, 5900 rpm for Western Digital versus 7200 rpm for the Seagate drives.

Our Updated 6TB Hard Drive Comparison

For our expanded comparison, let’s first look at the current stats for each drive model as of April 27, 2015:

Comparing Seagate and Western Digital 6TB drives

The Operational Environment

As noted, the initial evaluation was done with v3.0 Storage Pods. Subsequently we switched over to v4.5 Storage Pods and the new drives from both vendors were deployed into the newer pods. One of the primary differences between the two different Storage Pod versions is the use of SATA 6Gb/s (SATA III) in the v4.5 pods versus SATA 3Gb/s (SATA II) in the v3.0 pods.

The Backblaze cloud backup service currently receives about 140,000 GB of data from our customers each day. Data arrives in similarly sized encrypted chunks. On any given day, multiple Storage Pods accept the data as it arrives. The data is passed to a Storage Pod, if that Pod is busy, the data is passed to the next pod in line. Over the course of a day this results in all available Storage Pods being given the same opportunity to accept data at the same rate.

We tracked and recorded the Storage Pods filled with the 6TB Seagate and Western Digital drives. We started with the day they went online and continued each day until the pods were 80% full. Once they reach this point, the pods are designed to reduce the amount of data they accept.

Western Digital 6TB Drives

Let’s start with Western Digital. Below we compare the Western Digital 6TB drives from the different Storage Pods models (v3.0 and v4.5). While a specific Storage Pod ID is referenced, it is representative of all similarly configured Storage Pods.

Western Digital 6TB Drives

A quick look would seem to indicate that the Western Digital drives accepted less data per day in the newer version Storage Pods. The following table sharpens that observation.

blog_compare_WD_pods

Seagate 6TB Drives

Now we’ll compare the Seagate 6TB drives in the different Storage Pods models. As noted previously, when a specific Storage Pod ID is shown, it is representative of all similarly configured Storage Pods.

Seagate 6TB Drive Comparison

For the Seagate drives, when installed in a v4.5 Storage Pod, they load substantially more data on average each day then when installed in a v3.0 pod. The following table summarizes the difference:

Comparing Seagate 6TB Drives

Comparing Seagate to Western Digital

Let’s compare the Seagate and WD 6TB drives in the v4.5 Storage Pod:

Seagate vs Western Digital

In the v4.5 Pod, the Seagate drives consistently finished in 32-34 days while the Western Digital systems took much longer. This was over the same observation period in the same environment. Breaking this down into a table we see:

Comparing Seaagte vs WD 6TB drives

Given these observations, the Seagate drives in v4.5 Storage Pod compare favorably to the WD drives in the v3.0 pod.

What Changed

This time the Seagate 6TB drives loaded data faster than the WD 6TB drives. This result was observed across multiple Storage Pods and held true even when we normalized the data to account for variances in the amount of data received during the observation periods as well as the total number of Storage Pods available for data storage on any given day.

We believe the primary reason for the difference is the use of SATA 6 Gb/s in the v4.5 Storage Pods versus the use of SATA 3 Gb/s in the v3.0 pods. More precisely, our use of SATA 6 Gb/s let us take advantage of the faster spindle speed for the Seagate drive (7200 versus 5900 rpm). This allowed the Seagate drives to accept more data on average over the observation period.

As always, we’re reporting what we’ve observed on our environment. If you or someone you know works on hard drive internals we’d love to hear your theories. Please feel free to join the conversation.

What About Western Digital?

The results do not mean Western Digital is shut out. Both the Seagate and WD drives work in our environment and both drives store data in a reasonable amount of time. Besides, once a Storage Pod is full (or nearly full), we just need the hard drives inside to keep spinning, waiting for the day when a customer needs to recover their data. It’s not exciting, but in this case that’s a good thing.
