Getting Rid of Your Mac? Here’s How to Securely Erase a Hard Drive or SSD

By | May 29th, 2018

erasing a hard drive and a solid state drive

What do I do with a Mac that still has personal data on it? Do I take out the disk drive and smash it? Do I sweep it with a really strong magnet? Is there a difference in how I handle a hard drive (HDD) versus a solid-state drive (SSD)? Well, taking a sledgehammer or projectile weapon to your old machine is certainly one way to make the data irretrievable, and it can be enormously cathartic as long as you follow appropriate safety and disposal protocols. But there are far less destructive ways to make sure your data is gone for good. Let me introduce you to secure erasing.

Which Type of Drive Do You Have?

Before we start, you need to know whether you have a HDD or a SSD. To find out, or at least to make sure, you click on the Apple menu and select “About this Mac.” Once there, select the “Storage” tab to see which type of drive is in your system.

The first example, below, shows a SATA Disk (HDD) in the system.

SATA HDD

In the next case, we see we have a Solid State SATA Drive (SSD), plus a Mac SuperDrive.

Mac storage dialog showing SSD

The third screenshot shows an SSD, as well. In this case it’s called “Flash Storage.”

Flash Storage

Make Sure You Have a Backup

Before you get started, you’ll want to make sure that any important data on your hard drive has moved somewhere else. OS X’s built-in Time Machine backup software is a good start, especially when paired with Backblaze. You can learn more about using Time Machine in our Mac Backup Guide.

With a local backup copy in hand and secure cloud storage, you know your data is always safe no matter what happens.

Once you’ve verified your data is backed up, roll up your sleeves and get to work. The key is OS X Recovery — a special part of the Mac operating system since OS X 10.7 “Lion.”

How to Wipe a Mac Hard Disk Drive (HDD)

NOTE: If you’re interested in wiping an SSD, see below.

  1. Make sure your Mac is turned off.
  2. Press the power button.
  3. Immediately hold down the command and R keys.
  4. Wait until the Apple logo appears.
  5. Select “Disk Utility” from the OS X Utilities list. Click Continue.
  6. Select the disk you’d like to erase by clicking on it in the sidebar.
  7. Click the Erase button.
  8. Click the Security Options button.
  9. The Security Options window includes a slider that enables you to determine how thoroughly you want to erase your hard drive.

There are four notches to that Security Options slider. “Fastest” is quick but insecure — data could potentially be rebuilt using a file recovery app. Moving that slider to the right introduces progressively more secure erasing. Disk Utility’s most secure level erases the information used to access the files on your disk, then writes zeroes across the disk surface seven times to help remove any trace of what was there. This setting conforms to the DoD 5220.22-M specification.

  1. Once you’ve selected the level of secure erasing you’re comfortable with, click the OK button.
  2. Click the Erase button to begin. Bear in mind that the more secure method you select, the longer it will take. The most secure methods can add hours to the process.

Once it’s done, the Mac’s hard drive will be clean as a whistle and ready for its next adventure: a fresh installation of OS X, being donated to a relative or a local charity, or just sent to an e-waste facility. Of course you can still drill a hole in your disk or smash it with a sledgehammer if it makes you happy, but now you know how to wipe the data from your old computer with much less ruckus.

The above instructions apply to older Macintoshes with HDDs. What do you do if you have an SSD?

Securely Erasing SSDs, and Why Not To

Most new Macs ship with solid state drives (SSDs). Only the iMac and Mac mini ship with regular hard drives anymore, and even those are available in pure SSD variants if you want.

If your Mac comes equipped with an SSD, Apple’s Disk Utility software won’t actually let you zero the hard drive.

Wait, what?

In a tech note posted to Apple’s own online knowledgebase, Apple explains that you don’t need to securely erase your Mac’s SSD:

With an SSD drive, Secure Erase and Erasing Free Space are not available in Disk Utility. These options are not needed for an SSD drive because a standard erase makes it difficult to recover data from an SSD.

In fact, some folks will tell you not to zero out the data on an SSD, since it can cause wear and tear on the memory cells that, over time, can affect its reliability. I don’t think that’s nearly as big an issue as it used to be — SSD reliability and longevity has improved.

If “Standard Erase” doesn’t quite make you feel comfortable that your data can’t be recovered, there are a couple of options.

FileVault Keeps Your Data Safe

One way to make sure that your SSD’s data remains secure is to use FileVault (see All About FileVault: Encryption for Your Mac). FileVault is whole-disk encryption for the Mac. With FileVault engaged, you need a password to access the information on your hard drive. Without it, that data is encrypted.

There’s one potential downside of FileVault — if you lose your password or the encryption key, you’re screwed: You’re not getting your data back any time soon. Based on my experience working at a Mac repair shop, losing a FileVault key happens more frequently than it should.

When you first set up a new Mac, you’re given the option of turning FileVault on. If you don’t do it then, you can turn on FileVault at any time by clicking on your Mac’s System Preferences, clicking on Security & Privacy, and clicking on the FileVault tab. Be warned, however, that the initial encryption process can take hours, as will decryption if you ever need to turn FileVault off.

With FileVault turned on, you can restart your Mac into its Recovery System (by restarting the Mac while holding down the command and R keys) and erase the hard drive using Disk Utility, once you’ve unlocked it (by selecting the disk, clicking the File menu, and clicking Unlock). That deletes the FileVault key, which means any data on the drive is useless.

FileVault doesn’t impact the performance of most modern Macs, though I’d suggest only using it if your Mac has an SSD, not a conventional hard disk drive.

Securely Erasing Free Space on Your SSD

If you don’t want to take Apple’s word for it, if you’re not using FileVault, or if you just want to, there is a way to securely erase free space on your SSD. It’s a little more involved but it works.

Before we get into the nitty-gritty, let me state for the record that this really isn’t necessary to do, which is why Apple’s made it so hard to do. But if you’re set on it, you’ll need to use Apple’s Terminal app. Terminal provides you with command line interface access to the OS X operating system. Terminal lives in the Utilities folder, but you can access Terminal from the Mac’s Recovery System, as well. Once your Mac has booted into the Recovery partition, click the Utilities menu and select Terminal to launch it.

From a Terminal command line, type:

diskutil secureErase freespace VALUE /Volumes/DRIVE

That tells your Mac to securely erase the free space on your SSD. You’ll need to change VALUE to a number between 0 and 4. 0 is a single-pass run of zeroes; 1 is a single-pass run of random numbers; 2 is a 7-pass erase; 3 is a 35-pass erase; and 4 is a 3-pass erase. DRIVE should be changed to the name of your hard drive. To run a 7-pass erase of your SSD drive in “JohnB-Macbook”, you would enter the following:

diskutil secureErase freespace 2 /Volumes/JohnB-Macbook

And remember, if you used a space in the name of your Mac’s hard drive, you need to insert a leading backslash before the space. For example, to run a 35-pass erase on a hard drive called “Macintosh HD” you enter the following:

diskutil secureErase freespace 3 /Volumes/Macintosh\ HD

Something to remember is that the more extensive the erase procedure, the longer it will take.

When Erasing is Not Enough — How to Destroy a Drive

If you absolutely, positively need to be sure that all the data on a drive is irretrievable, see this Scientific American article (with contributions by Gleb Budman, Backblaze CEO), How to Destroy a Hard Drive — Permanently.
